INTRODUCTION

INTRODUCTION

Increase your brand presence

Increase your brand presence

Increase your brand presence

up to

60% More Footfall

60% More Footfall

60% More Footfall

Faster Content Iterations

Faster Content Iterations

Faster Content Iterations

Easy Content Management

Easy Content Management

Easy Content Management

Low Reliance on Labour

Low Reliance on Labour

Low Reliance on Labour

High Color Accuracy and Tone Matching

High Color Accuracy and Tone Matching

High Color Accuracy and Tone Matching

A new era in branding, advertising (DOOH), and visual communication has arrived. Static content is now a relic of the past. Traditional billboards, flex banners, and static signage are giving way to vibrant, dynamic displays. In an age of fierce competition and dwindling attention spans, captivating your audience demands more than ever before.


Reyansh Outdoor is our cutting-edge DOOH solution—crafted for brands that aim to stand out, captivate, and convert. Its seamless brilliance must be experienced to be believed.

The name Reyansh is inspired by both Anglo and Sanskrit roots—Ray, a stream of photons, and Ansh, meaning a part of something greater. The name embodies our mission: to harness the precision of optical physics and present it through a familiar, approachable identity.

As the world becomes increasingly digitized, the need for digital mediums to convey digital content is inevitable. While print may still be cost-effective today, its decline is imminent—driven by rising material and labor costs, limited scalability, and the growing demand for agility in communication.


Reyansh Outdoor eliminates the inefficiencies of print. No more replacing massive printed banners, worrying about color accuracy, or managing logistical constraints. With remote content management, instant updates, and unparalleled visual impact, our LED video walls empower your brand to stay agile, relevant, and memorable.

Reduce variables. Maximize impact. Expand your market footprint—with Reyansh Outdoor.

Increase your brand presence

up to

60% More Footfall

Faster Content Iterations

Easy Content Management

Low Reliance on Labour

High Color Accuracy and Tone Matching

A new era in branding, advertising (DOOH), and visual communication has arrived. Static content is now a relic of the past. Traditional billboards, flex banners, and static signage are giving way to vibrant, dynamic displays. In an age of fierce competition and dwindling attention spans, captivating your audience demands more than ever before.


Reyansh Outdoor is our cutting-edge DOOH solution—crafted for brands that aim to stand out, captivate, and convert. Its seamless brilliance must be experienced to be believed.

The name Reyansh is inspired by both Anglo and Sanskrit roots—Ray, a stream of photons, and Ansh, meaning a part of something greater. The name embodies our mission: to harness the precision of optical physics and present it through a familiar, approachable identity.

As the world becomes increasingly digitized, the need for digital mediums to convey digital content is inevitable. While print may still be cost-effective today, its decline is imminent—driven by rising material and labor costs, limited scalability, and the growing demand for agility in communication.


Reyansh Outdoor eliminates the inefficiencies of print. No more replacing massive printed banners, worrying about color accuracy, or managing logistical constraints. With remote content management, instant updates, and unparalleled visual impact, our LED video walls empower your brand to stay agile, relevant, and memorable.

Reduce variables. Maximize impact. Expand your market footprint—with Reyansh Outdoor.

F

E

A

T

U

R

E

S

TrueHue Technology

TrueHue Technology

TrueHue Technology

16,384 Shades of Gray

16,384 Shades of Gray

16,384 Shades of Gray

7680Hz Refresh Rate

7680Hz Refresh Rate

7680Hz Refresh Rate

≤85% Rec2020 Coverage

≤85% Rec2020 Coverage

≤85% Rec2020 Coverage

≥200,000:1 Contrast Ratio

≥200,000:1 Contrast Ratio

≥200,000:1 Contrast Ratio

240 Hz Frame Rate

240 Hz Frame Rate

240 Hz Frame Rate

Expert Calibration

Expert Calibration

Expert Calibration

6000 nits Max Brightness

6000 nits Max Brightness

6000 nits Max Brightness

3 Years Warranty

3 Years Warranty

3 Years Warranty

Highly Modular

Highly Modular

Highly Modular

Cloud Screen Control

Cloud Screen Control

Cloud Screen Control

4,396 Billion Colors

4,396 Billion Colors

4,396 Billion Colors

Sustainability

Sustainability

Sustainability

IP65

IP65

IP65

FEATURES

TrueHue Technology

16,384 Shades of Gray

7680Hz Refresh Rate

≤85% Rec2020 Coverage

≥200,000:1 Contrast Ratio

240 Hz Frame Rate

Expert Calibration

6000 nits Max Brightness

3 Years Warranty

Highly Modular

Cloud Screen Control

4,396 Billion Colors

Sustainability

IP65

CABINET

MATERIALS

CABINET

MATERIALS

V

A

R

I

A

N

T

S

VARIANTS

P4

P4

P4S

P4S

P4X

P4X

P3

P3

P3S

P3S

P3X

P3X

P2.5X

P2.5X

Technical Specifications

Technical

Specifications

Pixel Pitch:

P4

P3

P2.5

Variants:

P3

P3S

P3X

Cabinet

Materials:

Mild Steel, Aluminium Die Casting

Dimensions:

960mm x 960mm x 75mm 640mm x 640mm x 75mm Custom (Only available in Mild Steel)

Resolutions:

312 x 312 208 x 208 Custom (Only for mild steel)

Service Access:

Rear Front (Only available in Mild Steel)

Active Cooling:

1 Fan

Calibration

Supported:

Brightness, Chroma

Brightness Uniformity:

≥90%

Chroma Uniformity:

≥90%

Calibration Depth:

14 bits

Color Temperature:

2,000K - 10,000K

Module

Dimensions:

320mm x 160mm x 16mm

Pixel Pitch:

3.076mm

Resolution:

104 x 52

Pixel Density:

105,625 Dots per sqm

Technology:

Surface Mount Diode (SMD)

Scan Rate:

1/16

Video

Refresh Rate:

up to 3840 Hz

Frame Rate:

≤60 Hz

Anamorphic/Naked-eye-3D Ready:

No

Optimal Viewing Distance:

≥3m or ≥10 ft

LED

Technology:

TrueHue MiniLED

Manufacturer:

GKGD or Similar

Lamp Type:

SMD1415

Subpixel Configuration:

1R 1G 1B

Material of Leads:

Iron

Material of Contact to Leads:

Copper

Durability, Storage and Operation

Dust and Water Reistance:

IP65 (Resistant to moderate dust storms and light water jets)

Storage Conditions:

-20°C to 60°C @ 10% to 90%; Non-Condensing

Operation Conditions:

-10°C to 50°C @ 10% to 90%; Non-Condensing

Energy

AC Input:

100-240V, 50/60Hz; 15A

SMPS Efficiency:

~60-80%

SMPS Output:

5V 60A

Maximum Power Consumption:

≤800W/sqm or ≤75W/sqft when screen is white @ D65 and 100% Brightness

Average Power Consumption:

≤500W/sqm or ≤47W/sqft

Surge Protection:

Limited

Redundancy:

No

Semiconductor Lifespan:

≤100,000 Hours

Heat Dissipation per sqm:

3,002 BTU/hr

Warranty and Support

Warranty:

2 Years Standard

Warranty Extension:

None

Spares supplied:

3% of the system

Support:

Up to 7 Years

Priority Support:

None

Color

Bitdepth

14 bits per channel

Luminance Levels (Grayscale):

16,384 Levels

Color Gamut Coverage:

≤85% Rec2020/BT2020 ; ≥110% sRGB

Color Reproduction:

4,396 Billion Colors (4.4 Trillion Colors)

Maximum Brightness:

≤4500 nits (cd/sqm)

Peak Brightness:

≤5000 nits (cd/sqm)

Contrast Ratio:

Static Contrast: ≥6000:1 Dynamic Contrast Ratio: ≥200,000:1

Viewing Angle (H/V):

155°/155°

Pixel Pitch:

P4

P3

P2.5

Variants:

P3

P3S

P3X

Cabinet

Materials:

Mild Steel, Aluminium Die Casting

Dimensions:

960mm x 960mm x 75mm 640mm x 640mm x 75mm Custom (Only available in Mild Steel)

Resolutions:

312 x 312 208 x 208 Custom (Only for mild steel)

Service Access:

Rear Front (Only available in Mild Steel)

Active Cooling:

1 Fan

Calibration

Supported:

Brightness, Chroma

Brightness Uniformity:

≥90%

Chroma Uniformity:

≥90%

Calibration Depth:

14 bits

Color Temperature:

2,000K - 10,000K

Module

Dimensions:

320mm x 160mm x 16mm

Pixel Pitch:

3.076mm

Resolution:

104 x 52

Pixel Density:

105,625 Dots per sqm

Technology:

Surface Mount Diode (SMD)

Scan Rate:

1/16

Video

Refresh Rate:

up to 3840 Hz

Frame Rate:

≤60 Hz

Anamorphic/Naked-eye-3D Ready:

No

Optimal Viewing Distance:

≥3m or ≥10 ft

LED

Technology:

TrueHue MiniLED

Manufacturer:

GKGD or Similar

Lamp Type:

SMD1415

Subpixel Configuration:

1R 1G 1B

Material of Leads:

Iron

Material of Contact to Leads:

Copper

Durability, Storage and Operation

Dust and Water Reistance:

IP65 (Resistant to moderate dust storms and light water jets)

Storage Conditions:

-20°C to 60°C @ 10% to 90%; Non-Condensing

Operation Conditions:

-10°C to 50°C @ 10% to 90%; Non-Condensing

Energy

AC Input:

100-240V, 50/60Hz; 15A

SMPS Efficiency:

~60-80%

SMPS Output:

5V 60A

Maximum Power Consumption:

≤800W/sqm or ≤75W/sqft when screen is white @ D65 and 100% Brightness

Average Power Consumption:

≤500W/sqm or ≤47W/sqft

Surge Protection:

Limited

Redundancy:

No

Semiconductor Lifespan:

≤100,000 Hours

Heat Dissipation per sqm:

3,002 BTU/hr

Warranty and Support

Warranty:

2 Years Standard

Warranty Extension:

None

Spares supplied:

3% of the system

Support:

Up to 7 Years

Priority Support:

None

Color

Bitdepth

14 bits per channel

Luminance Levels (Grayscale):

16,384 Levels

Color Gamut Coverage:

≤85% Rec2020/BT2020 ; ≥110% sRGB

Color Reproduction:

4,396 Billion Colors (4.4 Trillion Colors)

Maximum Brightness:

≤4500 nits (cd/sqm)

Peak Brightness:

≤5000 nits (cd/sqm)

Contrast Ratio:

Static Contrast: ≥6000:1 Dynamic Contrast Ratio: ≥200,000:1

Viewing Angle (H/V):

155°/155°
